Z890-Creator WiFi
All You Need for Maximum Productivity
The ProArt Z890-CREATOR WIFI empowers creators of all levels by maximizing the performance of the latest Intel® Core™ Ultra Processor (Series 2) processors with 16+1+2+2 team power stages, DDR5 slots, PCIe® 5.0 and lightning-fast connectivity including dual Thunderbolt™ 5 ports, 10G and 2.5G Ethernet, and WiFi 7.
This motherboard manifests a professional, elegant and precise vision for content creators of all kinds, with a style elevated by tone-on-tone layers of black infused with metallic gold touches. A subtly designed I/O cover provides a sleek and sophisticated look while concealing the premium connectors within.
Support OC
AMD
Memories Type Support
DDR5
Number of M.2 Support
5
Series Motherboard
Z
MODEL SERIES
ProArt
MANUFACTURER
Asus
COLOR
Black & Gold
CPU SOCKET
LGA1851
Chipset
Intel® Z890 Chipset
M.2 Slots
5 x
SATA PORTS
4 x
RAM SLOTS
4 x DIMM slots, max. 256GB, DDR5
PCIE Slot
Intel® Core™ Ultra Processors (Series 2) * 2 x PCIe 5.0 x16 slots (supports x16 or x8/x8 modes) Intel® Z890 Chipset *1 x PCIe 4.0 x16 slot (supports x4 mode)
Audio
2 x Gold-plated audio jacks
Wi-fi & Bluetooth
Wi-Fi 7 - Bluetooth® v5.4
USB PORTS
Rear USB (Total 10 ports) 2 x Thunderbolt™ 5 ports (2 x USB Type-C®) 1 x USB4 / Thunderbolt™ port (1 x USB Type-C®) 6 x USB 10Gbps ports (6 x Type-A ) 1 x USB 2.0 port (1 x Type-A ) Front USB (Total 5 ports) 1 x USB 20Gbps (supports USB Type-C®) 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports 1 x USB 2.0 header supports 2 additional USB 2.0 ports USB Type-C® power delivery output: max. 5V/3A
