Intel® Socket LGA 1700：Support 13th and 12th Gen Series Processors
Unparalleled Performance：Hybrid 6+2+1 Phases Digital VRM Solution
Dual Channel DDR4：4*DIMMs XMP Memory Module Support
Next Generation Storage：2*PCIe 4.0 x4 M.2 Connectors
M.2 Thermal Guard：To Ensure M.2 SSD Performance
EZ-Latch：PCIe 4.0x16 Slot with Quick Release Design
Fast Networks：2.5GbE LAN
Extended Connectivity：Rear USB-C® 10Gb/s, DP, HDMI
Smart Fan 6：Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
Q-Flash Plus：Update BIOS Without Installing the CPU, Memory and Graphics Card
Support OC
Intel
Memories Type Support
DDR4
Number of M.2 Support
2
Series Motherboard
B
MODEL SERIES
B760M DS3H DDR4
MANUFACTURER
GIGABYTE
COLOR
black
CPU SOCKET
LGA 1700
Chipset
Intel B760
SATA PORTS
4 x SATA 6Gb/s
RAM SLOTS
4x288pin (DDR4)
PCIE Slot
1 x PCI Express 4.0 x16
PCIE GEN
4.0
Audio
3 x audio jacks
USB PORTS
1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2 support 5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header) 2 x USB 2.0/1.1 ports on the back panel Chipset+2 USB 2.0 Hubs: 4 x USB 2.0/1.1 ports
BLUETOOTH
Bluetooth 5.3
