We Provide the Frame, You Create the Art
The CORSAIR FRAME 5000D RS is a modular and spacious mid-tower PC case featuring InfiniRail™ Fan Mounting System, RapidRoute 2.0 cable management, and is compatible with reverse connector motherboards.
Includes
- Fully-modular design for next-level customization
- 4x RS140 Fans with daisy-chain connections
- InfiniRail Fan Mounting System for easier building
- Triple 360mm radiator support
- GPU anti-sag stabilization arm
- Compatible with reverse connector motherboards
- RapidRoute 2.0 pegboard motherboard tray and cable looms
Cooler Type Support
Both Cooler
Air Cooler Height Support
175
Radiator Size Values
360/
240/
120/
280/
140/
420/
Built in Fans Number
4
Fans Number Support
12
MODEL SERIES
FRAME 5000D RS
MANUFACTURER
Corsair
Motherboard Support
ATX E-ATX MicroATX Mini-ITX
COLOR
Black
Fan Options
Front: 3x 120mm, 3x 140mm, 2x 200mm Top: 3x 120mm, 3x 140mm Side: 3x 120mm, 3x 140mm Bottom: 2x 120mm Rear 1x 120mm, 1x 140mm PSU Shroud: 2x 120mm
Built in fans No.
4
Fans Number Support
12
HDD 3.5" Storage
2 x 3.5"
SSD 2.5" storage
6 x 2.5" Internal
Expansion Slots
Standard Expansion Slots 8 Vertical Expansion Slots 3
Number of USB 3.0
4
Number of USB C
1
Headphone/Microphone
1
Glass
Side
Weight
12.7 kg (Approx)
DIMENSIONS
250 x 542 x 556 (WxHxD mm)
