CORSAIR HXi Series Fully Modular Ultra-Low Noise Power Supplies deliver exceptional 80 PLUS Platinum efficient power and low-noise fluid dynamic bearing fan performance. ATX 3.0 and PCIe 5.0 compliance, HXi PSUs have every connection needed to power today’s most demanding PC upgrades. Powerful CORSAIR iCUE software enables custom fan curves, monitoring and adjusting power settings, and more thanks to a fully digital platform. Japanese 105°C-rated electrolytic capacitors deliver long life and reliability, backed by a tenyear warranty. Wake your computer faster and consume less power with Modern Standby sleep mode. Zero RPM mode ensures near-silent operation at low and medium loads. The HXi Series puts platinum power at your command.
Power Watt
0
Power Value Support
1,000
MODEL SERIES
HXi
MANUFACTURER
CORSAIR
COLOR
BLACK
FANS
140mm Fluid Dynamic Bearing
Main Connector
1x 24-pin ATX (24-pin) Connector
MTBF
100,000 hours
Input Voltage
100 - 240 V
Input Frequency Range
47 - 63 Hz
Input Current
13A-6.5A (100Va.c.-240Va.c.) 10A (200Va.c.-240Va.c.)
PCIE Connector
2x PCIe (6+2) Connectors
24pin count
1
8 Pin count
2 x 8 pin (4+4) EPS (CPU) / 4 x 8 pin (6+2) PCIe
SATA count
8 x SATA
Modularity
Full Modular
EFFICIENCY
80 PLUS Platinum
DIMENSIONS
180.09 mm x 150.11 mm x 86.11 mm
Weight
2.00 kg
