Timeless Elegance, Endless Performance
- Mid-tower chassis designed for advanced workstations and high-performance setups
- Compatible with back-connect motherboards for ultra-clean cable routing
- Supports up to E-ATX / EEB motherboards and dual PSU mounting orientations
- Comes pre-installed with 5 high-performance fans for optimal out-of-box airflow
- Tool-less front fan mounting system for effortless installation and maintenance
- Certified with PPLP for enhanced professional use compliance
Cooler Type Support
Both Cooler
Air Cooler Height Support
180
Radiator Size Values
360/
240/
120/
280/
Built in Fans Number
5
Fans Number Support
12
MODEL SERIES
LAN217W
MANUFACTURER
LIANLI
COLOR
White
Motherboard Support
SSI-EEB(Width Max 330mm) / E-ATX（Width Max 280mm） ATX / Micro-ATX/Mini-ITX
Fan Options
Front: 170mm x 2 (Included) / 140mm x 3 / 120mm x 3 Top: 3 x 120mm / 2 x 140mm Above PSU Shroud: 3 x 120mm (2 Included) Under the PSU shroud: 2 x 120mm Rear: 1x 140mm(Included) / 1x 120mm
Built in fans No.
Front: 170mm x 2 (Included) - Above PSU Shroud: 120mm (2 Included) - Rear: 1x 140mm(Included)
Fans Number Support
Front: 170mm x 2 (Included) / 140mm x 3 / 120mm x 3 Top: 3 x 120mm / 2 x 140mm Above PSU Shroud: 3 x 120mm (2 Included) Under the PSU shroud: 2 x 120mm Rear: 1x 140mm(Included) / 1x 120mm
SSD 2.5" storage
Back Connect Motherboard: 2 x 2.5″ SSD / 1 x 2.5″ SSD(behind MB) 2 x Drive Cage: 1 x 3.5″HDD+ 1 x 2.5″ SSD+(1 x 3.5″ HDD or 1 x 2.5″ SSD) PSU Shroud: 1 x 2.5″ SSD
Expansion Slots
7
Number of USB 3.0
2
Number of USB C
1
Headphone/Microphone
1
Glass
Side
DIMENSIONS
(D)482mm x (W)238mm x (H)503mm
