PCIe 4.0* Design, Gen3 x4 M.2, GbE LAN, Anti-Sulfur Resistor, Smart Fan 6
- Supports Intel® Core™ 14th/ 13th /12th processors
- Dual Channel Non-ECC Unbuffered DDR4, 2 DIMMs
- GbE LAN with Bandwidth Management
- NVMe PCIe 3.0 x4 M.2
- High Quality Audio Capacitors and Audio Noise Guard
- Smart Fan 6 Features Multiple Temperature Sensors , Hybrid Fan Headers with FAN STOP
- GIGABYTE APP Center, Simple and Easy Use
- Anti-Sulfur Resistors Design
Support OC
Intel
Memories Type Support
DDR4
Number of M.2 Support
1
Series Motherboard
H
موديل المنتج
H610M K
المصنع
Gigabyte
اللون
Black
قاعدة المعالج
LGA1700 socket
نوع الشريحة
Intel® H610 Express Chipset
آر جي بي
No
منافذ M.2
1 x M.2 Socket 3 connector
منافذ ساتا
2 x SATA 6Gb/s connectors
منافذ الذاكرة العشوائية
Support for DDR4 3200/3000/2933/2666/2400/2133 MT/s memory modules
منفذ PCIE
CPU: 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 Chipset: 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1
منافذ الصوت
3 x audio jacks
واي فاي وبلوتوث
No
منافذ يو إس بي
4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)/li> 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header)/li>
